Noise Dosimeter

Reference: Documentation

Features
Stacks Image 133
Built for Standardized Measurement: The Noise Dosimeter offers standard noise dose metrics, including frequency weighting, criterion levels, and exchange rates, defined by the ANSI S1.25 standard for personal noise dosimeters.
Stacks Image 136
Data Logging (Pro Feature): Log sound level data for up to 2 weeks at intervals as small as 0.1 seconds. Use the auto-save feature to keep logging data beyond 2 weeks, for as long as your device has disk space available.
Stacks Image 139
Save Data: Export signal level values and metadata to a data file (.csv, .mat, or .txt). Or, generate a high-resolution image of the display and save it to a PDF file.
Specifications
  • Input: 1 channel at a time, selected from any available input, output, or virtual output channels
  • Criterion Level: 80, 85, 90 dB
  • Threshold: 40, 50, 60, 70, 80, 90 dB
  • Exchange Rate: 3, 4, 5 dB
  • Frequency Weighting: Z (zero, or no weighting), A, C
  • A, C Frequency Weighting Supported Sample Rates (samples/second): 44100, 48000, 88200, 96000, 176400, 192000
  • Automatic Stop: Enable/Disable
    • Duration: 0.1 seconds up to 14 days, 23 hours, 59 minutes, 59.9 seconds
  • Data Logging (Pro Feature)
    • Log Size: Uses Automatic Stop Duration
    • Log Levels: Enable/Disable
    • Show in Log Plot: Noise Dose, Projected Dose, Time Weighted Average (TWA), Lp
    • Log Interval: User-defined, with constraints
      • Data Log Size > 72 hours: Log interval >= 10 seconds
      • Data Log Size > 8 hours: Log interval >= 1 seconds
      • Data Log Size <= 8 hours: Log interval >= 0.1 seconds
  • Notification Events (Pro Feature): Local Notifications
    • Auto-Stop
    • Dose Exceeds: User-definable noise dose limit
    • TWA Exceeds: User-definable noise dose limit
  • Bar Graph: Lp
    • Level divisions: 10
    • Autoscale: Auto
    • Level Axis: dB
  • Data Export
    • Data File Format: CSV, MAT, TXT
    • Image: PDF
    • Optionally include current location in exported data files.
  • Specifications Subject to Change
