Real-time XY Scope Tool
Features
Stacks Image 126
Save Data: Export waveforms and metadata to an audio file (.wav, .aif, or .caf) or a data file (.csv, .mat, or .txt). Or, generate a high-resolution image of the graph and save it to a PDF file.
Specifications
  • Input: 1 channel selectable for each of X and Y inputs, selected from any available input, output, or virtual output channels
  • Mid/Side Mode: X = (X-Y)/2, Y = (X+Y)/2
  • Graph
    • Horizontal divisions: 10
    • Vertical divisions: 10
    • Autoscale, independently selectable for X and Y: Off, Auto, Up, Down
    • Amplitude Scale, independently selectable for X and Y (Units/Div)
      • 1e-9, 2e-9, 3e-9, 4e-9, 5e-9, 6e-9, 8e-9, 10e-9, 20e-9, 30e-9, 40e-9, 50e-9, 60e-9, 80e-9, 100e-9, 200e-9, 300e-9, 400e-9, 500e-9, 600e-9, 800e-9, 1e-6, 2e-6, 3e-6, 4e-6, 5e-6, 6e-6, 8e-6, 10e-6, 20e-6, 30e-6, 40e-6, 50e-6, 60e-6, 80e-6, 100e-6, 200e-6, 300e-6, 400e-6, 500e-6, 600e-6, 800e-6, 1e-3, 2e-3, 3e-3, 4e-3, 5e-3, 6e-3, 8e-3,10e-3, 20e-3, 30e-3, 40e-3, 50e-3, 60e-3, 80e-3,100e-3, 200e-3, 300e-3, 400e-3, 500e-3, 600e-3, 800e-3, 1.0, 2.0, 3.0, 4.0, 5.0, 6.0, 8.0, 10.0, 20.0, 30.0, 40.0, 50.0, 60.0, 80.0, 100.0, 200.0, 300.0, 400.0, 500.0, 600.0, 800.0, 1e3, 2e3, 3e3, 4e3, 5e3, 6e3, 8e3, 10e3, 20e3, 30e3, 40e3, 50e3, 60e3, 80e3, 100e3, 200e3, 300e3, 400e3, 500e3, 600e3, 800e3
  • Data Export
    • Audio File Format: AIF, CAF, WAV
    • Data File Format: CSV, MAT, TXT
    • Image: PDF
  • Specifications Subject to Change
